Detailní popis produktu
Cena za ksDoplňkové parametry
| Kategorie: | Průmyslové konektory |
|---|---|
| Výrobce: | Harting |
| Series: | har-bus® 64 |
| Element: | Male connector |
| Description of the contact: | Angled |
| Features: | lead-free |
| Termination method: | Reflow soldering termination (THR) / Wave soldering termination |
| Connection type: | Motherboard to daughtercard / Extender card |
| Number of contacts: | 160 |
| Contact configuration: | Rows a, b, c, d and z, positions 1, 2, ... , 31, 32 |
| Leading contact on position: | d1 / d2 / d31 / d32 |
| PCB fixing: | With fixing flange / With snap-in clip |
| Contact rows: | 5 |
| Contact spacing (termination side): | 2.54 mm |
| Contact spacing (mating side): | 2.54 mm |
| Rated current: | 1 A |
| Rated current 2: | Rated current measured at 20 °C, see derating curve for details |
| Clearance distance: | 1.2 mm between 2 rows (a, b, c) / 1.2 mm between 2 rows (d, z) / 1.2 mm between 2 contacts in a row (a, b, c) / 1 mm between 2 contacts in a row (d, z) |
| Creepage distance: | 1.2 mm between 2 rows (a, b, c) / 1.2 mm between 2 rows (d, z) / 1.2 mm between 2 contacts in a row (a, b, c) / 1 mm between 2 contacts in a row (d, z) |
| Insulation resistance: | _1010 Ω |
| Contact resistance: | ≤20 mΩ for rows a, b, c / ≤30 mΩ for rows d, z |
| Limiting temperature: | '-55 ... +125 °C (during reflow soldering max. +240 °C for 15 s) |
| Insertion and withdrawal force: | ≤ 160 N |
| Performance level: | 1 / acc. to IEC 61076-4-113 |
| Mating cycles: | ≥ 500 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | IIIa (175 ≤ CTI _ 400) |
| Hot plugging: | No |
| Material (insert): | Liquid crystal polymer (LCP) |
| Colour (insert): | Beige |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni Mating side / Sn over Ni Termination side |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant |
| ELV status: | compliant |
| China RoHS: | e |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Not contained |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Lead / Nickel |
| Specifications: | IEC 61076-4-113 |
| UL / CSA: | UL 1977 ECBT2.E102079 / CSA-C22.2 No. 182.3 ECBT8.E102079 |
| Railway classification: | F1_I2 acc. to NFF 16-101_102 |
| Packaging size: | 100 |
| Net weight: | 26 g |
| Country of origin: | Germany |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140000032 |
| eCl@ss: | 27460201 PCB connector (board connector) |
