Detailní popis produktu
Cena za ks MOQ = 1 ksDoplňkové parametry
| Kategorie: | Průmyslové konektory |
|---|---|
| Výrobce: | Harting |
| Series: | har-modular® |
| Element: | Male connector |
| Description of the contact: | Angled |
| Termination method: | Reflow soldering termination (THR) / Wave soldering termination |
| Connection type: | Motherboard to daughtercard |
| Number of contacts: | 9 |
| Contact spacing (mating side): | 2.54 mm |
| Rated current: | 2 A |
| Clearance distance: | 1 mm in the module / 1.9 mm to module edge |
| Creepage distance: | 1 mm in the module / 1.8 mm to module edge |
| Insulation resistance: | _1011 Ω |
| Contact resistance: | ≤ 20 mΩ |
| Limiting temperature: | '-55 ... +125 °C (during reflow soldering max. +240 °C for 15 s) |
| Insertion and withdrawal force: | ≤ 9 N |
| Performance level: | 1 / acc. to IEC 60603-2 |
| Mating cycles: | ≥ 500 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | I (600 ≤ CTI) |
| Hot plugging: | No |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni Mating side / Sn over Ni Termination side |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant |
| ELV status: | compliant |
| China RoHS: | e |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Not contained |
| California Proposition 65 substances: | Not contained |
| UL / CSA: | UL 1977 ECBT2.E102079 / CSA-C22.2 No. 182.3 ECBT8.E102079 |
| Railway classification: | F1_I2 acc. to NFF 16-101_102 |
| Packaging size: | 20 |
| Net weight: | 3 g |
| Country of origin: | Romania |
| European customs tariff number: | 85389099 |
| GTIN: | 5713140197893 |
| eCl@ss: | 27460201 PCB connector (board connector) |
