02519091103
Kód: 02519091103
Široký sortiment
Tisíce produktů od světových výrobců.
Odborné poradenství
Technická podpora zkušeného týmu.
Rychlé dodání
Zboží skladem expedujeme obratem.
Certifikovaná kvalita
Komponenty splňující nejvyšší normy.
Detailní popis produktu
Cena za ks MOQ = 1 ksDoplňkové parametry
| Kategorie: | Průmyslové konektory |
|---|---|
| Výrobce: | Harting |
| Series: | har-modular® |
| Element: | Male connector |
| Description of the contact: | Angled |
| Termination method: | Reflow soldering termination (THR) / Wave soldering termination |
| Connection type: | Motherboard to daughtercard |
| Number of contacts: | 9 |
| Leading contact on position: | a3 |
| Contact spacing (mating side): | 2.54 mm |
| Rated current: | 2 A |
| Clearance distance: | 1 mm in the module / 1.9 mm to module edge |
| Creepage distance: | 1 mm in the module / 1.8 mm to module edge |
| Insulation resistance: | _1011 Ω |
| Contact resistance: | ≤ 20 mΩ |
| Limiting temperature: | '-55 ... +125 °C (during reflow soldering max. +240 °C for 15 s) |
| Insertion and withdrawal force: | ≤ 9 N |
| Performance level: | 1 / acc. to IEC 60603-2 |
| Mating cycles: | ≥ 500 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | I (600 ≤ CTI) |
| Hot plugging: | No |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni Mating side / Sn over Ni Termination side |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant |
| ELV status: | compliant |
| China RoHS: | e |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Not contained |
| California Proposition 65 substances: | Not contained |
| UL / CSA: | UL 1977 ECBT2.E102079 / CSA-C22.2 No. 182.3 ECBT8.E102079 |
| Railway classification: | F1_I2 acc. to NFF 16-101_102 |
| Packaging size: | 20 |
| Country of origin: | Romania |
| European customs tariff number: | 85389099 |
| GTIN: | 5713140197916 |
| eCl@ss: | 27460201 PCB connector (board connector) |
