Detailní popis produktu
Cena za ksDoplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | DIN 41612 |
| Element: | Female connector |
| Description of the contact: | Straight |
| Features: | lead-free |
| Termination method: | IDC insulation displacement termination |
| Connection type: | PCB to cable |
| Number of contacts: | 64 |
| Contact configuration: | Rows a and b, positions 1, 2, ... , 31, 32 |
| PCB fixing: | With fixing flange |
| Contact rows: | 2 |
| Contact spacing (termination side): | 2.54 mm |
| Contact spacing (mating side): | 2.54 mm |
| Rated current: | 1 A |
| Rated current 2: | Rated current measured at 20 °C, see derating curve for details |
| Clearance distance: | ≥ 1.2 mm |
| Creepage distance: | ≥ 1.2 mm |
| Insulation resistance: | _106 Ω |
| Contact resistance: | ≤ 20 mΩ |
| Limiting temperature: | '-55 ... +85 °C |
| Insertion and withdrawal force: | ≤ 60 N |
| Performance level: | 2 / acc. to IEC 60603-2 |
| Mating cycles: | ≥ 400 |
| Test voltage Ur.m.s.: | 1 kV (contact-contact) / 1.55 kV (contact-ground) |
| Isolation group: | IIIa (175 ≤ CTI _ 400) |
| Hot plugging: | No |
| Material (insert): | Thermoplastic resin, glass-fibre filled |
| Colour (insert): | RAL 7032 (pebble grey) |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni Mating side / Ni Termination side |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant |
| ELV status: | compliant |
| China RoHS: | e |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Not contained |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Antimony trioxide / Nickel |
| Specifications: | IEC 60603-2 |
| UL / CSA: | UL 1977 ECBT2.E102079 / CSA-C22.2 No. 182.3 ECBT8.E102079 |
| Railway classification: | F4_I3 acc. to NFF 16-101_102 |
| Packaging size: | 20 |
| Net weight: | 14.94 g |
| Country of origin: | Philippines |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140003606 |
| eCl@ss: | 27460201 PCB connector (board connector) |
