09554156612741
Kód: 09554156612741
Široký sortiment
Tisíce produktů od světových výrobců.
Odborné poradenství
Technická podpora zkušeného týmu.
Rychlé dodání
Zboží skladem expedujeme obratem.
Certifikovaná kvalita
Komponenty splňující nejvyšší normy.
Detailní popis produktu
Cena za role MOQ = 1 roleDoplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | D-Sub |
| Element: | Connector |
| Description of the contact: | Stamped / Straight |
| Termination method: | Reflow soldering termination (SMT) |
| Connection type: | Motherboard to daughtercard / Mezzanine |
| Number of contacts: | 37 |
| Contact spacing (termination side): | 2.76 mm |
| Rated current: | 5 A |
| Clearance distance: | ≥ 1 mm |
| Creepage distance: | ≥ 1 mm |
| Insulation resistance: | _ 5 x 109 Ω |
| Contact resistance: | ≤ 25 mΩ |
| Limiting temperature: | '-55 ... +125 °C (during reflow soldering max. +240 °C for 30 s) |
| Performance level: | 2 / acc. to CECC 75301-802 |
| Mating cycles: | ≥ 250 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | IIIa (175 ≤ CTI _ 400) |
| Hot plugging: | No |
| Material (insert): | Liquid crystal polymer (LCP) / Shell_ steel, nickel plated |
| Colour (insert): | Black |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant |
| ELV status: | compliant |
| China RoHS: | e |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Not contained |
| California Proposition 65 substances: | Not contained |
| Specifications: | DIN 41652 |
| UL / CSA: | UL 1977 ECBT2.E102079 / CSA-C22.2 No. 182.3 ECBT8.E102079 |
| Packaging size: | 1 |
| Net weight: | 2,555 g |
| Country of origin: | China |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140070448 |
| eCl@ss: | 27440214 D-Sub coupler |
