Detailní popis produktu
Cena za ksDoplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | D-Sub |
| Element: | Connector |
| Description of the contact: | Stamped / Angled |
| Termination method: | Reflow soldering termination (THR) |
| Connection type: | Motherboard to daughtercard |
| Number of contacts: | 37 |
| Contact spacing (termination side): | 2.76 mm |
| Rated current: | 6.5 A |
| Clearance distance: | ≥ 1 mm |
| Creepage distance: | ≥ 1 mm |
| Insulation resistance: | _1010 Ω |
| Contact resistance: | ≤ 10 mΩ |
| Limiting temperature: | '-55 ... +125 °C (during reflow soldering max. +240 °C for 15 s) |
| Performance level: | 2 / acc. to CECC 75301-802 |
| Mating cycles: | ≥ 250 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | II (400 ≤ CTI _ 600) |
| Hot plugging: | No |
| Material (insert): | Thermoplastic resin, glass-fibre filled (PCT) / Shell_ steel, nickel plated |
| Colour (insert): | Grey |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant with exemption |
| ELV status: | compliant with exemption |
| China RoHS: | 50 |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Yes |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Lead / Nickel |
| Specifications: | DIN 41652 |
| Packaging size: | 50 |
| Net weight: | 17.6 g |
| Country of origin: | Romania |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140079649 |
| eCl@ss: | 27440214 D-Sub coupler |
