09664566613
Kód: 09664566613
Široký sortiment
Tisíce produktů od světových výrobců.
Odborné poradenství
Technická podpora zkušeného týmu.
Rychlé dodání
Zboží skladem expedujeme obratem.
Certifikovaná kvalita
Komponenty splňující nejvyšší normy.
Detailní popis produktu
Popis produktu není dostupný
Doplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | D-Sub |
| Element: | Connector |
| Description of the contact: | Stamped / Angled |
| Termination method: | Reflow soldering termination (THR) |
| Connection type: | Motherboard to daughtercard |
| Number of contacts: | 37 |
| PCB fixing: | With board locks |
| Contact spacing (termination side): | 2.76 mm |
| Rated current: | 6.5 A |
| Clearance distance: | ≥ 1 mm |
| Creepage distance: | ≥ 1 mm |
| Insulation resistance: | _1010 Ω |
| Contact resistance: | ≤ 10 mΩ |
| Limiting temperature: | -55 ... +125 °C (during reflow soldering max. +240 °C for 15 s) |
| Performance level: | 2 / acc. to CECC 75301-802 |
| Mating cycles: | ≥ 250 |
| Test voltage Ur.m.s.: | 1 kV |
| Isolation group: | II (400 ≤ CTI _ 600) |
| Hot plugging: | No |
| Material (insert): | Thermoplastic resin, glass-fibre filled (PCT) / Shell_ steel, nickel plated |
| Colour (insert): | Grey |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Noble metal over Ni |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant with exemption |
| ELV status: | compliant with exemption |
| China RoHS: | 50 |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Yes |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Lead / Nickel |
| Specifications: | DIN 41652 |
| Packaging size: | 50 |
| Net weight: | 22.87 g |
| Country of origin: | Romania |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140085770 |
| eCl@ss: | 27440214 D-Sub coupler |
