09930030300
Kód: 09930030300
Široký sortiment
Tisíce produktů od světových výrobců.
Odborné poradenství
Technická podpora zkušeného týmu.
Rychlé dodání
Zboží skladem expedujeme obratem.
Certifikovaná kvalita
Komponenty splňující nejvyšší normy.
Detailní popis produktu
Cena za ks
MOQ = 1 ks
Doplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | Han® Board |
| Element: | Inserts |
| Description of the contact: | Angled |
| Termination method: | Wave soldering termination |
| Number of contacts: | 3 |
| Contact spacing (mating side): | 7.62 mm |
| Rated current: | 32 A |
| Rated current 2: | The current-carrying capacity depends significantly on the printed circuit board used, the conductor cross-section used and the specific installation situation. |
| Limiting temperature: | '-25 ... +125 °C / -5 ... +65 °C While mating or unmating |
| Mating cycles: | ≥ 75 |
| Material (insert): | Thermoplastic resin (PBT) |
| Colour (insert): | Black |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Silver plated |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant with exemption |
| ELV status: | compliant with exemption |
| China RoHS: | 50 |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Yes |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Lead |
| UL / CSA: | UL 1977 ECBT2.E235076 / CSA-C22.2 No. 182.3 ECBT8.E235076 |
| Packaging size: | 80 |
| Net weight: | 10.28 g |
| Country of origin: | Germany |
| European customs tariff number: | 85340090 |
| GTIN: | 5713140186712 |
| eCl@ss: | 27440205 Contact insert for industrial connectors |
