Detailní popis produktu
Cena za KS MOQ = 1 KSDoplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Ilme |
| Product type: | data connector |
| Series: | DT12 |
| Specification: | M12 entry / 8 poles, X-coded, straight / RJ45 entry / Cat.6A, angled / |
| Weight: | 10,00 g |
| Operating temperature range (min, max): | '-40°C … +85°C |
| Main material: | zinc diecast, brass |
| Other materials: | Contacts / copper alloy |
| Colour: | RAL 9005 black |
| SCIP number: | 8b60cf05-8f5f-42af-80f1-e79cea373159 |
| EAN13 code: | 8015747241090 |
| Packaging description: | Carton box |
| Packaging quantity: | 1 Pcs |
| Packaging EAN code: | 8015747246460 |
| Sub-packaging description: | Plastic bag |
| Sub-packaging EAN barcode: | 8015747283458 |
| Sub-packaging quantity: | 1 Pcs |
| China RoHs - EFUP: | e |
| Connection type: | M12 |
| Contact resistance: | ≤ 5 MΩ |
| Gender: | Female |
| Insulation resistance: | ≥ 100 MΩ |
| Mating cycles: | ≥ 100 |
| REACH SVHC substances: | No |
| RoHs conformity: | Compliant |
| UL 94 flammability rating: | V-0 |
| Current: | / 1 A / |
| Characteristics according to EN 61984: | 1 A 50 V 0,8 kV 2 |
| Pollution degree: | 2 |
| Rated impulse withstand voltage: | 0,8 kV |
| Voltage: | / 50 /   |
