14120216001000 - SVK Elektronik, s.r.o.

Katalogové číslo: 14120216001000

har-flexicon 5,00 MTV-2 BK

Cena za ks

Series: har-flexicon®

Element: Header

Connection type: PCB to cable

Number of contacts: 2

Contact rows: 1

Contact spacing (termination side): 5 mm

Rated current: ‌ 15 A

Rated current 2: ‌ 15 A

Insulation resistance: _109 Ω

Contact resistance: _109 Ω

Limiting temperature: '-40 ... +110 °C

Isolation group: I (600 ≤ CTI)

Material (insert): Polyamide (PA) / Polyphthalamide (PPA)

Colour (insert): Black

Material (contacts): Copper alloy

Surface (contacts): Sn over Ni Mating side / Sn over Ni Termination side

Material flammability class acc. to UL 94: V-0

RoHS: compliant

ELV status: compliant

China RoHS: e

REACH Annex XVII substances: Not contained

REACH Annex XIV substances: Not contained

REACH SVHC substances: Not contained

UL / CSA: UL 1059 XCFR2.E314677 / CSA-C22.2 No. 158-10 XCFR8.E314677

Packaging size: 300

Net weight: 1.63 g

Country of origin: Italy

European customs tariff number: 85366990

GTIN: 5713140112957

eCl@ss: 27460201 PCB connector (board connector)
