14310315402000
Kód: 14310315402000
Široký sortiment
Tisíce produktů od světových výrobců.
Odborné poradenství
Technická podpora zkušeného týmu.
Rychlé dodání
Zboží skladem expedujeme obratem.
Certifikovaná kvalita
Komponenty splňující nejvyšší normy.
Detailní popis produktu
Cena za ksDoplňkové parametry
| Kategorie: | Náš sortiment |
|---|---|
| Výrobce: | Harting |
| Series: | har-flexicon® |
| Element: | Connector |
| Termination method: | Screw termination |
| Connection type: | PCB to cable |
| Number of contacts: | 3 |
| Contact rows: | 1 |
| Contact spacing (termination side): | 3.81 mm |
| Rated current: | 10 A |
| Rated current 2: | 10 A |
| Limiting temperature: | '-40 ... +110 °C |
| Isolation group: | I (600 ≤ CTI) |
| Material (insert): | Polyamide (PA) / Polyphthalamide (PPA) |
| Colour (insert): | Green |
| Material (contacts): | Copper alloy |
| Surface (contacts): | Sn Mating side |
| Material flammability class acc. to UL 94: | V-0 |
| RoHS: | compliant with exemption |
| ELV status: | compliant with exemption |
| China RoHS: | 50 |
| REACH Annex XVII substances: | Not contained |
| REACH ANNEX XIV substances: | Not contained |
| REACH SVHC substances: | Yes |
| California Proposition 65 substances: | Yes |
| California Proposition 65 substances 2: | Lead |
| UL / CSA: | UL 1059 XCFR2.E314677 / CSA-C22.2 No. 158-10 XCFR8.E314677 |
| Packaging size: | 200 |
| Net weight: | 2.26 g |
| Country of origin: | Italy |
| European customs tariff number: | 85366990 |
| GTIN: | 5713140114814 |
| eCl@ss: | 27460201 PCB connector (board connector) |
